Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ABB Bailey IMAMI01 |
| Type | Auto Manual Interface Module |
| System Compatibility | INFI-90 Distributed Control System |
| Function | Provides interface for switching between automatic and manual control modes |
| Power Supply Voltage | 15 V DC nominal |
| Power Consumption | Approx. 2.5 W |
| Input Type | Digital input signals from control devices |
| Output Type | Digital output to field devices and control systems |
| Number of Channels | 8 input/output configurable channels |
| Communication Interface | INFI-90 system bus |
| Isolation | Galvanic isolation between inputs, outputs, and system bus |
| Diagnostic Functions | Mode status monitoring, input/output error detection |
| Redundancy Support | Supported through system configuration |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95% RH, non-condensing |
| Protection Class | IP20 |
| Compliance Standards | IEC, CE, and ANSI industrial standards |
| Dimensions | 200 × 100 × 50 mm |
| Weight | 0.5 kg |
FAQ
FAQ
Q1: What is the primary function of the ABB Bailey IMAMI01 module?
A1: The IMAMI01 allows seamless switching between automatic and manual control modes for field devices within the INFI-90 system.
Q2: How many input and output channels does the IMAMI01 support?
A2: It supports 8 configurable input/output channels for control and monitoring functions.
Q3: What types of signals can the IMAMI01 handle?
A3: The module handles digital input signals from control devices and provides digital outputs to the system and field devices.
Q4: Does the IMAMI01 provide galvanic isolation?
A4: Yes, it provides full galvanic isolation between inputs, outputs, and the system bus to ensure signal integrity.
Q5: Can the IMAMI01 support redundancy?
A5: Yes, redundancy is supported through system configuration to enhance reliability in critical control applications.
Q6: What communication interface does the IMAMI01 use?
A6: It communicates via the INFI-90 system bus for integration with ABB Bailey Distributed Control Systems.
Q7: What diagnostic functions are included in the IMAMI01?
A7: The module includes mode status monitoring, input/output error detection, and signal validation diagnostics.
Q8: What environmental conditions can the IMAMI01 operate under?
A8: It operates effectively within 0°C to +60°C and 5%–95% relative humidity, non-condensing.
