ABB Bailey INSOE01 Sequence of Events (SOE) Server Node

FAQ

Q1: What is the ABB Bailey INSOE01 used for?
A: It is a Sequence of Events Server Node used to collect, time-stamp and manage event information in an ABB Bailey INFI 90 DCS.

Q2: Is INSOE01 a single electronic module?
A: No. INSOE01 is a server-node configuration/kit, consisting primarily of INNIS11, INSEM01 and INTKM01 plus the required termination units and cables.

Q3: What modules are included in INSOE01?
A: The standard configuration contains INNIS11 Network Interface Slave, INSEM01 Sequence of Events Master and INTKM01 Time Keeper Master.

Q4: What does the INSEM01 do?
A: The INSEM01 manages the distributed SOE system and communicates with both the INNIS11 and INTKM01 modules.

Q5: What does the INTKM01 do?
A: The INTKM01 Time Keeper Master provides the timing function required for accurate SOE event timestamps.

Q6: Which DCS does INSOE01 belong to?
A: It belongs to the ABB Bailey INFI 90 / Net 90 control-system family. ABB’s module inventory also lists INSOE01 among the Net 90 modules.

Q7: Is INSOE01 suitable for event and disturbance analysis?
A: Yes. Its purpose is to capture the chronological sequence of process events with accurate time information, making it useful for trip analysis, fault investigation and process-event monitoring.

Q8: What are the dimensions and weight of INSOE01?
A: A supplier lists approximately 51 × 178 × 102 mm for the kit and approximately 0.7 kg. Actual shipping dimensions may be larger when the termination units and cables are packaged.

ABB Bailey INSOE01
