Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | NMFC05 |
| Input Channels | Up to 16 analog inputs (with IMASM01) |
| Input Signal Types | -10V to +10V, 0–10V, 1–5V, 0–5V, 0–1V, 4–20mA (system or external power) |
| Mounting | NFTP01 Field Termination Panel |
| Power Consumption | 20 mA per input @ +24 VDC |
| Operating Temperature | 0°C to 70°C |
| Relative Humidity | 0–95% up to 55°C, 0–45% up to 70°C (non-condensing) |
| Atmospheric Pressure | Sea level to 3000 m |
| Cooling Requirements | No cooling required when used in Bailey cabinets |
| EMC Recommendations | Keep at least 2 meters from radio transmitters; cabinet doors must remain closed |
| Certification | CSA certified for ordinary (non-hazardous) location |
| Dimensions | 200 × 100 × 30 mm |
| Weight | 0.86 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What types of analog input signals does the NMFC05 support?
A1: It supports multiple analog signals including 4–20mA, -10V to +10V, 0–10V, 1–5V, 0–5V, and 0–1V.
Q2: Which slave modules are compatible with the NMFC05?
A2: It works with IMASM01, IMASI02, and IMFBS01 analog slave modules.
Q3: Is hot swapping supported?
A3: No, hot swapping is not supported. Always power down the system before installation or maintenance.
Q4: How is power supplied to the NMFC05?
A4: Power is supplied via a +24VDC source with approximately 20 mA per input channel.
Q5: What precautions should be taken during installation?
A5: Install on an NFTP01 panel, use anti-static measures, and avoid touching circuitry directly.
Q6: Is additional cooling required?
A6: No, additional cooling is not necessary within Bailey standard enclosures.
Q7: What is the maximum altitude for NMFC05 operation?
A7: It is rated for use up to 3000 meters above sea level.
Q8: Is the device resistant to corrosive environments?
A8: No, it must be used in a non-corrosive environment.
