Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | PHBAIN1200S200 |
| Series | ABB Bailey INFI 90 |
| Type | Analog Input Base Module |
| Function | Provides base connection and interface for analog input modules |
| Input Channels Supported | Up to 8 analog input channels |
| Input Signal Type | Current or voltage (configurable) |
| Signal Range | 0–10 VDC or 4–20 mA |
| Power Supply | 24 VDC nominal |
| Input Isolation | Galvanic isolation between channels and system ground |
| Accuracy | ±0.1% of full scale |
| Response Time | <10 ms |
| Communication Interface | Backplane connection to INFI 90 system bus |
| Mounting Type | Rack or panel mount |
| Protection Features | Overvoltage, overcurrent, and reverse polarity protection |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Humidity | 5% to 95% non-condensing |
| Compliance | CE, UL, and CSA certified |
| Dimensions | 280 × 100 × 75 mm |
| Weight | 1.8 kg |
FAQ
FAQ
Q1: What is the main function of the ABB Bailey PHBAIN1200S200 Analog Input Base?
A1: It serves as the interface base for analog input modules, enabling the connection of analog signals from field devices to the ABB INFI 90 control system.
Q2: How many analog channels can this base support?
A2: The PHBAIN1200S200 supports up to 8 independent analog input channels.
Q3: What types of analog signals are compatible with this module base?
A3: It can handle both current (4–20 mA) and voltage (0–10 VDC) input signals.
Q4: Is there electrical isolation between channels?
A4: Yes, the design includes galvanic isolation to prevent ground loops and interference between input channels.
Q5: How is this base module powered?
A5: It operates from a nominal 24 VDC power supply, provided through the system’s backplane.
Q6: What protection features are included in the PHBAIN1200S200?
A6: The unit provides protection against overvoltage, overcurrent, and reverse polarity, ensuring reliable performance.
Q7: Can this analog input base be used with other ABB Bailey INFI 90 modules?
A7: Yes, it is designed for full compatibility with the INFI 90 series analog input and controller modules.
Q8: In what types of applications is this base typically used?
A8: It is commonly used in process automation, power generation, and industrial control systems requiring precise analog data acquisition.
