Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | PHBAIN2200S100 |
| Series | ABB Bailey INFI 90 |
| Type | Analog Input Base Module |
| Function | Provides mechanical support and electrical connections for analog input modules |
| Supported Channels | Up to 8 analog input channels |
| Input Signal Type | Voltage or current (configurable per channel) |
| Signal Range | 0–10 VDC or 4–20 mA |
| Input Impedance | 250 Ω (current input), 100 kΩ (voltage input) |
| Power Supply | 24 VDC nominal |
| Accuracy | ±0.1% of full-scale |
| Isolation | Channel-to-system galvanic isolation |
| Response Time | <10 ms typical |
| Communication Interface | Backplane connection to INFI 90 control bus |
| Protection Features | Surge, reverse polarity, and overvoltage protection |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Humidity | 5–95% non-condensing |
| Cooling Method | Natural convection |
| Mounting Type | Rack or panel mount |
| Compliance | CE, UL, CSA certified |
| Dimensions | 280 × 100 × 75 mm |
| Weight | 1.8 kg |
FAQ
FAQ
Q1: What is the purpose of the ABB Bailey PHBAIN2200S100 Analog Input Base?
A1: It serves as the mounting and electrical interface for analog input modules, facilitating the connection of field analog signals to the INFI 90 system.
Q2: How many analog input channels does this base support?
A2: The PHBAIN2200S100 supports up to 8 analog input channels for flexible process monitoring.
Q3: What types of input signals can be connected to this base?
A3: It supports both current (4–20 mA) and voltage (0–10 VDC) input signals.
Q4: Does the PHBAIN2200S100 provide signal isolation?
A4: Yes, it provides galvanic isolation between input channels and the system to reduce interference and improve signal integrity.
Q5: What protective features are included in this analog input base?
A5: It includes built-in surge, reverse polarity, and overvoltage protection for enhanced system reliability.
Q6: How is the base powered and connected within the INFI 90 system?
A6: The module is powered through the system backplane, which also handles communication with the control processor.
Q7: Is this module base compatible with other ABB Bailey analog modules?
A7: Yes, it is fully compatible with standard ABB Bailey analog input modules within the INFI 90 control architecture.
Q8: What are the main application areas for the PHBAIN2200S100?
A8: It is commonly used in industrial automation, process control, and power generation systems requiring accurate and reliable analog signal processing.
