Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | SPQRS22 |
| Manufacturer | ABB Bailey |
| Product Family | Symphony Plus HR Series / Harmony Rack I/O |
| Product Type | Quick Response I/O Module |
| Main Function | High-speed process control and I/O signal processing |
| Response Rate | 12 ×/second |
| Analog Inputs | 4 × 4–20 mA |
| Digital Inputs | 3 optically isolated channels |
| Digital Outputs | 4 optically isolated, independently configurable open-collector channels |
| Analog Outputs | 2 × 4–20 mA |
| Total I/O Channels | 13 channels |
| Power Supply | +5 VDC, +15 VDC, −15 VDC, +24 VDC |
| +5 VDC Consumption | 100 mA typical / 180 mA max. |
| +15 VDC Consumption | 27 mA typical / 35 mA max. |
| −15 VDC Consumption | 23 mA typical / 30 mA max. |
| +24 VDC Consumption | 46 mA typical / 65 mA max. |
| Operating Temperature | 0 to 70°C |
| Dimensions | Approx. 35.56 × 177.80 × 298.45 mm |
| Approx. Product Weight | 0.2 kg |
| Country of Origin | Sweden |
FAQ
FAQ
Q1: What is the ABB Bailey SPQRS22 used for?
A: It is a Quick Response I/O Module used for high-speed process control in ABB Bailey Symphony Plus systems.
Q2: How many analog inputs does SPQRS22 have?
A: It has 4 independently configured 4–20 mA analog inputs.
Q3: How many digital inputs and outputs does SPQRS22 have?
A: It provides 3 digital inputs and 4 digital outputs. The digital inputs are optically isolated, while the outputs are independently configurable open-collector outputs.
Q4: How many analog outputs does SPQRS22 have?
A: It has 2 analog outputs, both 4–20 mA.
Q5: What is the response speed of SPQRS22?
A: The specified response is 12 times per second (12X/sec).
Q6: What is the difference between SPQRS22 and SPCIS22?
A: They are functionally similar, but SPQRS22 has approximately 10× faster response. Its trade-off is lower noise rejection compared with SPCIS22.
Q7: What system is SPQRS22 compatible with?
A: It is designed for the ABB Bailey Symphony Plus HR Series / Harmony Rack I/O system.
Q8: What are the dimensions and weight of SPQRS22?
A: The published dimensions are approximately 35.56 × 177.80 × 298.45 mm, with a supplier-listed weight of approximately 0.2 kg.
