Technical Specifications
| Item | Description |
|---|---|
| Model | 23BA20 / GSNE000700R5312 |
| Product Type | Binary Output Board |
| System Compatibility | ABB industrial control and protection systems |
| Output Type | Multiple digital outputs for actuators, relays, and protection functions |
| Output Voltage Level | Typically 24 VDC (system-dependent) |
| Output Drive Capability | Suitable for relay coils, trip commands, lamps, and light control loads |
| Isolation | Electrical isolation between outputs and system electronics |
| Response Time | Fast digital response |
| Communication | Backplane communication with the controller |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Mounting Method | Rack-mounted plug-in module |
| Dimensions | 100 × 150 × 30 mm |
| Weight | 0.226 kg |
FAQ
FAQ
Q1: What is the main application of the 23BA20 board?
A1: It provides digital output signals for relay control, protection tripping, and status commands.
Q2: What is the output voltage?
A2: Typically 24 VDC, depending on the system configuration.
Q3: Does the board include output isolation?
A3: Yes, the outputs are isolated from the internal system circuitry.
Q4: Is it suitable for high-speed protection operations?
A4: Yes, it features fast response suitable for protection tasks.
Q5: Can it drive relay coils directly?
A5: Yes, it supports typical relay coil loads and light-duty actuators.
Q6: How is the board installed?
A6: It plugs into the designated slot of the ABB control rack.
Q7: Does it require an external power supply?
A7: No, it is powered through the system backplane.
Q8: Is field replacement supported?
A8: Yes, replacement can be performed during scheduled maintenance shutdowns.
