Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | 5SHX1060H0003 |
| Order Code | 3BHB020538R0001 |
| Type | IGCT (Integrated Gate-Commutated Thyristor) Module |
| Maximum Voltage | 4500 V |
| Maximum Current | 3000 A |
| Switching Frequency | High (application-dependent) |
| Control Method | Integrated gate driver circuitry |
| Mounting Type | Bolt-mounted |
| Operating Temperature | -40°C to +125°C |
| Storage Temperature | -40°C to +125°C |
| Cooling Method | Forced air or liquid cooling |
| Package Type | Module format |
| Application Areas | Medium/high-voltage converters, industrial drives, power grid systems |
| Dimensions | 190 x 140 x 38 mm |
| Weight | 1.2 kg |
FAQ
FAQ
Q1: What type of power device is the ABB 5SHX1060H0003?
A1: It is an IGCT (Integrated Gate-Commutated Thyristor) module combining features of GTO and IGBT for high-voltage, high-current applications.
Q2: What are the main application areas of this module?
A2: It is mainly used in medium to high-voltage converters, industrial drives, and power transmission systems.
Q3: What is the maximum voltage rating of this module?
A3: The maximum rated voltage is 4500 volts.
Q4: What is the maximum current the module supports?
A4: It supports up to 3000 amperes of current.
Q5: Does this IGCT module include a gate driver?
A5: Yes, it features an integrated gate driver for simplified system integration.
Q6: How is the module cooled?
A6: It can be cooled by forced air or liquid, depending on the application design.
Q7: What are the physical dimensions and weight of the module?
A7: The module measures 190 x 140 x 38 mm and weighs approximately 1.2 kg.
Q8: Is it suitable for high-frequency switching environments?
A8: Yes, the IGCT is capable of high switching frequencies and is ideal for performance-critical applications.
