Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ABB 5SHY3545L0014 3BHE023784R0001 |
| Type | Thyristor Module |
| Function | High-power switching and control in industrial applications |
| Voltage Rating | 4500 V |
| Current Rating | 3545 A |
| Gate Trigger Voltage | 3 V (typical) |
| Gate Trigger Current | 200 mA (typical) |
| Repetitive Peak Off-State Voltage (VDRM) | 4500 V |
| Repetitive Peak Reverse Voltage (VRRM) | 4500 V |
| Operating Temperature | -40 °C to +125 °C |
| Storage Temperature | -40 °C to +125 °C |
| Dimensions | 120 x 26 x 120 mm |
| Weight | 1.32 kg |
| Cooling Method | Forced air or liquid cooling |
| Application Areas | Drives, converters, power control, and HVDC systems |
FAQ
FAQ
1. What is the ABB 5SHY3545L0014 3BHE023784R0001 used for?
-
It is used for high-power switching and control in applications like drives, converters, and HVDC systems.
2. What is the maximum voltage rating of this module?
-
The maximum voltage rating is 4500 V.
3. What is the maximum current rating?
-
The maximum current rating is 3545 A.
4. What cooling method is recommended?
-
It can use either forced air or liquid cooling.
5. What is the typical gate trigger voltage and current?
-
Gate trigger voltage is about 3 V, and gate trigger current is about 200 mA.
6. What are the dimensions and weight of this module?
-
Dimensions are 120 x 26 x 120 mm, and weight is approximately 1.32 kg.
7. Can it operate in extreme temperatures?
-
Yes, it operates in a range from -40 °C to +125 °C.
8. In which industries is this thyristor module commonly used?
-
It is used in industries like power transmission, steel manufacturing, and industrial motor control.
