Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ABB 89AR30 |
| Type | Relay Unit |
| Contact Configuration | 2 NO + 2 NC (2 Normally Open + 2 Normally Closed) |
| Rated Voltage | 24–250 V AC/DC |
| Rated Current | 6 A AC/DC |
| Electrical Life | 1 × 10⁵ operations |
| Mechanical Life | 1 × 10⁷ operations |
| Response Time | 10 ms (operate) / 5 ms (release) |
| Mounting | DIN Rail / Panel Mount |
| Dimensions | 220 × 100 × 80 mm |
| Weight | 0.6 kg |
| Operating Temperature | -25°C to +60°C |
FAQ
FAQ
Q1: What is the contact configuration of this relay unit?
A1: It has 2 normally open (NO) and 2 normally closed (NC) contacts.
Q2: What is the rated voltage range?
A2: Supports 24–250 V AC/DC.
Q3: What is the maximum rated current?
A3: Maximum rated current is 6 A.
Q4: What is the electrical life?
A4: Electrical life is 1 × 10⁵ operations.
Q5: What is the mechanical life?
A5: Mechanical life is 1 × 10⁷ operations.
Q6: What is the response time?
A6: Response time is 10 ms to operate and 5 ms to release.
Q7: How can this relay unit be mounted?
A7: It can be mounted on a DIN rail or a panel.
Q8: What is the operating temperature range?
A8: The operating temperature range is -25°C to +60°C.
