Manufacturer：ABB
Product Number：ACS880-01-246A-3
Product Type：Low Voltage AC Variable Frequency Drive (VFD)
Origin：Sweden
Dimensions：965 × 300 × 386 mm
Weight：68 kg
Order number：3ABD00035954-D
FAQ
FAQ
Q1: What is the ABB ACS880-01-246A-3?
A1: The ABB ACS880-01-246A-3 is a low-voltage industrial wall-mounted AC drive designed for demanding motor control applications. It provides precise speed and torque control using ABB Direct Torque Control (DTC) technology.
Q2: What does Product ID 3ABD00035954-D represent?
A2: 3ABD00035954-D is the ABB Product ID for the ACS880-01-246A-3. It identifies a 400 V class, 132 kW, 246 A ACS880 industrial drive model.
Q3: What motor size can this drive control?
A3: The drive is rated for 132 kW (180 HP) motors in normal-duty operation with a rated output current of 246 A. For heavy-duty applications, it supports approximately 110 kW (150 HP) motors with a current rating of 206 A.
Q4: What input power supply is required?
A4: The ACS880-01-246A-3 requires a three-phase 380–415 VAC power supply with an input frequency range of 47.5–63 Hz.
Q5: Which motor control technology does it use?
A5: It uses ABB’s Direct Torque Control (DTC) technology and supports Scalar (V/Hz) control, providing accurate torque response and stable motor operation.
Q6: What communication options are available?
A6: The ACS880-01-246A-3 supports industrial communication options including Modbus RTU, PROFIBUS, PROFINET IO, EtherNet/IP, CANopen, DeviceNet, and other fieldbus protocols through optional communication adapters.
Q7: What are the physical dimensions of the drive?
A7: The ACS880-01-246A-3 uses the R8 frame and measures approximately 965 × 300 × 386 mm (H × W × D).
Q8: What is the weight of the drive?
A8: The ACS880-01-246A-3 has a net weight of approximately 68 kg.
