Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Family | AFS670 |
| Product Type | Managed Industrial Ethernet Switch |
| Mounting / Form Factor | 19-inch rack |
| Network Role | Managed Ethernet switch for substation and industrial networks |
| Ethernet Ports | Up to 24 ports |
| Gigabit Ethernet | Up to 4 GbE ports, depending on configuration |
| Fast Ethernet | Up to 20 Fast Ethernet ports, depending on configuration |
| Port Types | RJ45, optical fiber, SFP and other configurable interfaces |
| Switching Functions | Managed Layer 2 Ethernet switching |
| RSTP | Yes |
| SNTP | Yes |
| PTPv2 | No hardware timestamping; PTP simple mode supported |
| Station Bus | Supported |
| Process Bus | Not supported |
| Redundancy | Redundant power supply options available |
| Power Supply | Depending on configuration: 110–240 V AC or 110–250 V DC; low-voltage 24 V DC versions also available |
| Operating Temperature | Industrial/substation environment; exact range depends on configuration |
| Protection / Standards | IEC 61850-3, IEEE 1613, EN 61131, cUL 508 |
| Dimensions | 448 × 310 × 44 mm or 448 × 345 × 44 mm, depending on configuration |
| Weight | Approx. 3.9–5.6 kg, depending on configuration |
FAQ
FAQ
Q1: What is the ABB AFS670?
A: The AFS670 is a ruggedized, managed industrial Ethernet switch designed primarily for electrical substations and utility automation networks.
Q2: How many ports does the AFS670 support?
A: The AFS670 can support up to 24 Ethernet ports, depending on the selected configuration.
Q3: Is the AFS670 a managed switch?
A: Yes. It is a managed Ethernet switch with network-management and redundancy functions such as RSTP and SNTP.
Q4: Does the AFS670 support Gigabit Ethernet?
A: Yes. Certain configurations provide up to four Gigabit Ethernet ports, using electrical, optical or SFP interfaces.
Q5: Does it support redundant power supplies?
A: Yes. The AFS670 can be equipped with redundant power units, which is useful for high-availability substation networks.
Q6: What power supply does the AFS670 use?
A: Depending on the specific version, it can use high-voltage AC/DC supplies such as 110–240 V AC or 110–250 V DC. Lower-voltage 24 V DC configurations are also available.
Q7: Is the AFS670 suitable for IEC 61850 applications?
A: Yes. ABB documentation lists the AFS670 among switches suitable for substation environments and indicates compliance with IEC 61850-3 and IEEE 1613 requirements.
Q8: What are the dimensions and weight of the AFS670?
A: The standard 19-inch unit is approximately 448 mm wide and 44 mm high, with depth of either 310 or 345 mm depending on configuration. Weight is approximately 3.9–5.6 kg depending on the installed modules and power supply.
