Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | AO845A 3BSE045584R1 |
| Product Type | Analog Output Module |
| Number of Output Channels | 8 isolated analog outputs |
| Output Signal Range | 0–20 mA / 4–20 mA configurable |
| Resolution | 12 bits |
| Load Resistance | 0–750 Ω |
| Accuracy | ±0.1% of span |
| Update Rate | 10 ms per channel |
| Power Supply Voltage | 24 V DC (from system backplane) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5–95% non-condensing |
| EMC Compliance | EN 61000-6-2 / EN 61000-6-4 |
| Dimensions (mm) | 45 × 102 × 119 mm |
| Weight (kg) | 0.21 kg |
FAQ
FAQ
Q1: What is the primary function of the AO845A module?
A1: It provides multiple isolated analog current outputs for process control applications in ABB control systems.
Q2: How many channels does this module have?
A2: It has 8 isolated analog output channels.
Q3: Can the output range be configured?
A3: Yes, it supports both 0–20 mA and 4–20 mA ranges, selectable via system configuration.
Q4: Is the AO845A hot-swappable?
A4: Yes, it supports hot-swapping within compatible ABB system hardware.
Q5: What type of backplane voltage does it use?
A5: It operates on 24 V DC supplied from the system backplane.
Q6: What is the module’s accuracy?
A6: The accuracy is ±0.1% of the configured output span.
Q7: In what environments can it be used?
A7: It can operate in temperatures from 0°C to +55°C and humidity levels of 5–95% non-condensing.
Q8: Does the module meet industrial EMC standards?
A8: Yes, it complies with EN 61000-6-2 and EN 61000-6-4 standards.
