Technical Specifications
| Item | Specification |
|---|---|
| Model | ABB AX522 (Ordering No. 1SAP250000R0001) |
| Type | Analog Input Module |
| Product Category | PLC / DCS I/O Module |
| Product Family | ABB S900 / Advant Controller I/O System |
| Function | Provides isolated analog input channels for process signal measurement |
| Number of Input Channels | 2 channels |
| Supported Signal Types | 0–20 mA, 4–20 mA, 0–10 V (configurable per channel) |
| Input Resolution | High-resolution analog conversion |
| Input Accuracy | Industrial-grade precision |
| Input Impedance | Appropriate impedance for voltage and current inputs |
| Isolation | Galvanic isolation between channels and backplane |
| Status Indication | LED indicators for module power and channel status |
| Mounting Method | DIN rail or rack mounting via terminal base |
| Field Wiring Connection | Screw terminal or plug-in terminal base |
| Operating Temperature Range | –20 °C to +55 °C |
| Storage Temperature Range | –40 °C to +70 °C |
| Protection Rating | IP20 |
| Housing Material | Industrial-grade plastic |
| Application Environment | Industrial automation and control cabinets |
| Compatibility | ABB S900 / Advant Controller I/O systems |
| Dimensions | Approx. 20 mm × 104 mm × 104 mm |
| Weight | Approximately 0.13 kg |
FAQ
FAQ
Q1: What is the primary function of the ABB AX522 module?
It provides two isolated analog input channels for measuring process signals such as current or voltage in industrial automation systems.
Q2: How many input channels does the AX522 support?
The module supports 2 independent analog input channels.
Q3: What types of analog signals can the AX522 measure?
It can measure current signals (0–20 mA, 4–20 mA) and voltage signals (0–10 V), configurable per channel.
Q4: Does the module provide electrical isolation?
Yes, the AX522 provides galvanic isolation between channels and the backplane to ensure accurate and safe signal processing.
Q5: How are analog signals connected to the AX522?
Signals are connected via screw terminal connectors or a plug-in terminal base for secure field wiring.
Q6: Does the AX522 provide status indication?
Yes, it includes LED indicators for module power and channel activity/status.
Q7: Can the AX522 operate in typical industrial environments?
Yes, it is designed to operate in industrial automation control cabinets within its specified temperature range.
Q8: What are the physical dimensions and weight of the AX522?
The module measures approximately 20 mm × 104 mm × 104 mm and weighs about 0.13 kg.
