Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | CI 773F |
| Order Code | 3BDH000395R0001 |
| Communication Protocol | PROFIBUS DP Master |
| Transmission Speed | 9.6 kbit/s to 12 Mbit/s |
| Interface Type | D-Sub terminal, 9-pin |
| Power Consumption | Typ. 80 mA via 24 V terminal of CPU module |
| Power Dissipation | 1.6 W |
| Hot Swap | Supported |
| Redundancy | Controller redundancy supported, line via RLM02 |
| Protection Class | IP20 |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Max Altitude | < 2000 m |
| Humidity | Max. 95%, non-condensing |
| Corrosion Protection | G3 compliant according to ISA 71.04 |
| EMC Standards | EN 61000-6-4, EN 61000-6-2 |
| Safety Standards | IEC/EN 61010-1, IEC/EN 61010-2-201 |
| Hazardous Locations | cULus Class 1 Div 2 |
| RoHS Compliance | Directive 2011/65/EU, (EU) 2015/863 |
| WEEE Compliance | Directive 2012/19/EU |
| CE Marking | Yes |
| Dimensions (W×H×D) | 28 × 135 × 75 mm |
| Weight | 0.096 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What communication protocol does the CI 773F module support?
A1: It supports the PROFIBUS DP master protocol and is compatible with AC 700F and AC 900F systems.
Q2: Is hot swapping supported on this module?
A2: Yes, hot swapping is supported for easy maintenance and replacement.
Q3: Does it support line redundancy?
A3: Line redundancy is not built-in but can be achieved using an external RLM02 module.
Q4: What is the protection rating of the CI 773F?
A4: It is rated IP20, suitable for installation inside control cabinets.
Q5: What is the operating temperature range of this module?
A5: The operating temperature range is -20°C to +70°C, ideal for industrial environments.
Q6: Is the CI 773F certified for CE and RoHS compliance?
A6: Yes, it is CE marked and compliant with RoHS directives 2011/65/EU and 2015/863.
Q7: What are the power requirements for the module?
A7: It typically consumes 80 mA, powered via the CPU module’s 24 V terminal.
Q8: How is the PROFIBUS network connected?
A8: The module connects via a 9-pin D-Sub connector to the PROFIBUS DP network.
