Technical Specifications
| Parameter | Specification |
|---|---|
| Model | CI534V02 |
| Article Number | 3BSE010700R1 |
| Communication Protocol | MODBUS |
| Interface Type | MultiVendor Interface (MVI) |
| Number of Communication Ports | 2 Ports, both using same protocol |
| Installation Type | Rack mounted, 19-inch standard width |
| Mechanical Mounting | Subrack-mounted |
| Operating Voltage | Supplied by backplane (standard system voltage) |
| Electrical Connection | Plug-in contacts, primary connector per EN 60320, C20 |
| Protocol Support | MODBUS via MVB (MultiVendor Bus) |
| Application | AC 400 Series, e.g., AC410/450 controllers |
| Dimensions (W x D x H) | 238.5 x 27 x 108 mm |
| Weight | 0.155 kg |
FAQ
FAQ
Q1: What protocol does the CI534V02 module support?
A1: It supports the MODBUS protocol using the MultiVendor Interface structure.
Q2: How many communication ports are available on CI534V02?
A2: The module provides two communication ports with identical protocol functionality.
Q3: Is CI534V02 suitable for use with non-ABB systems?
A3: Yes, the MultiVendor Interface is designed for integration with third-party equipment.
Q4: What kind of systems is CI534V02 compatible with?
A4: It is compatible with ABB Advant Controller 400 Series, including models like AC410 and AC450.
Q5: Can CI534V02 be installed in standard 19-inch racks?
A5: Yes, it is mechanically designed for rack mounting in 19-inch systems.
Q6: Does CI534V02 require external power?
A6: No, it is powered via the subrack backplane.
Q7: What is the module’s main application?
A7: It serves as a communication interface to connect Advant Controllers to MODBUS networks.
Q8: Is there any redundancy support with CI534V02?
A8: Redundancy is possible by using duplicated communication boards, modems, and cables as per system design.
