Technical Specifications
| Item | Description |
|---|---|
| Product Model | ABB CI873K01 3BSE056899R1 |
| Product Type | Communication Interface Module |
| Manufacturer | ABB |
| Function | Provides communication between AC 800M controllers and PROFINET IO networks |
| Supported Protocol | PROFINET IO (RT and IRT) |
| Communication Speed | 100 Mbit/s full duplex |
| Interface Type | Dual RJ45 Ethernet ports |
| Power Supply | 24 V DC |
| Power Consumption | Approx. 3.5 W |
| Operating Temperature | 0 to 55 °C |
| Storage Temperature | -25 to 70 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Type | DIN-rail or rack-mounted |
| Diagnostic Functions | LED indicators for power, link, and activity |
| Firmware Update | Supported via Ethernet |
| Compatibility | ABB AC 800M Controller Series |
| Dimensions | 59 × 186 × 127.5 mm |
| Weight | 0.7 kg |
FAQ
FAQ
Q1: What is the primary function of the ABB CI873K01 module?
It serves as a PROFINET IO communication interface between ABB AC 800M controllers and field devices.
Q2: Which communication protocol does the CI873K01 support?
It supports the PROFINET IO protocol, including both RT and IRT communication.
Q3: Is the module compatible with all AC 800M controllers?
Yes, it is fully compatible with ABB’s AC 800M controller family.
Q4: What is the communication speed of the CI873K01?
It operates at 100 Mbit/s in full-duplex mode.
Q5: How is the module powered?
The module requires a 24 V DC power supply.
Q6: Does the CI873K01 support redundant configurations?
Yes, it supports redundancy to enhance communication reliability.
Q7: Are diagnostic LEDs available on the module?
Yes, LEDs are provided to indicate power status, network link, and activity.
Q8: Can the firmware be updated?
Yes, firmware updates can be performed via the Ethernet interface.
