Technical Specifications
| Item | Specification |
|---|---|
| Product Model | ABB DC523 1SAP240500R0001 |
| Product Type | Digital Input/Output Module |
| Digital Inputs | 16 channels |
| Digital Outputs | 16 channels |
| Input Voltage | 24 V DC |
| Output Voltage | 24 V DC |
| Output Current | Max. 0.5 A per channel |
| Isolation | Opto-isolated channels to bus |
| Power Supply | 24 V DC |
| Power Consumption | Max. 6 W |
| Communication | System bus |
| Operating Temp. | 0 ~ 55 ℃ |
| Storage Temp. | -40 ~ 70 ℃ |
| Humidity | 5% ~ 95% (non-condensing) |
| Mounting | DIN rail |
| Dimensions | 62 x 76 x 67.5 mm |
| Weight | 0.115 kg |
FAQ
FAQ
Q1: What is the main function of the ABB DC523 module?
It provides digital input and output interfaces for process control and device status monitoring.
Q2: How many input and output channels does the module provide?
It provides 16 digital input channels and 16 digital output channels.
Q3: What is the rated voltage for inputs and outputs?
Both inputs and outputs operate at 24 V DC.
Q4: What is the maximum current per output channel?
Each output channel supports up to 0.5 A.
Q5: Does the module include isolation protection?
Yes, channels are opto-isolated from the system bus.
Q6: What is the power consumption of the module?
The maximum power consumption is 6 W.
Q7: How is the module installed?
It is installed via DIN rail mounting for modular integration.
Q8: What are the module’s dimensions and weight?
The dimensions are 62 x 76 x 67.5 mm mm, and the weight is 0.115 kg.
