Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | ABB DCS800-S02-2000-05-B |
| Series | ABB DCS800 DC Drive Series |
| Manufacturer | ABB |
| Product Type | Regenerative DC Drive (4-quadrant) |
| Application | Heavy industrial DC motor control |
| Input Voltage | 400–480 VAC, 3-phase |
| Output Voltage | 500 VDC (armature) |
| Rated Current Class | Up to ~1490–2000 A (frame dependent) |
| Control Method | Thyristor-based DC motor control |
| Operating Mode | Motoring + Regenerative braking |
| Cooling Method | Forced air cooling (cabinet system) |
| Protection Class | IP00 (cabinet installed) |
| Dimensions (H × W × D) | Approx. 813 × 508 × 406 mm (32 × 20 × 16 in) |
| Weight | Approx. 109 kg (240 lbs) |
| Mounting Type | Cabinet / wall-mounted drive system |
| Motor Type | DC motors (armature + field winding) |
| Typical Industries | Steel, mining, paper mills, cranes, extrusion systems |
FAQ
FAQ
Q1: What is the ABB DCS800-S02-2000-05-B used for?
It is used for high-power DC motor control in heavy industrial applications such as steel mills, cranes, and large production lines.
Q2: Is this a VFD (Variable Frequency Drive)?
No. It is a DC drive designed specifically for DC motors, not AC motor speed control.
Q3: What does 4-quadrant operation mean?
It means the drive can operate in forward/reverse motoring and braking modes, including regenerative energy feedback to the supply system.
Q4: What cooling method is used?
The unit uses forced-air cooling and must be installed inside a properly ventilated industrial cabinet.
Q5: What is the typical weight of this drive?
Approximately 109 kg (240 lbs), depending on configuration and frame variant.
Q6: Why is the size relatively large?
Because it handles very high current levels (up to ~2000 A class), requiring heavy-duty power electronics and thermal management.
Q7: Can it control AC motors?
No. It is only designed for DC motors with armature and field windings.
Q8: What industries commonly use this model?
It is widely used in steel production, mining systems, paper machines, hoisting equipment, and extrusion lines.
