Technical Specifications
| Parameter | Description |
|---|---|
| Module Type | Digital Input Module |
| Input Voltage Range | 18–30 V DC |
| Rated Input Voltage | 24 V DC |
| Input Current | 4.3 mA @ 24 V DC |
| Number of Channels | 32 channels |
| Grouping | 2 isolated groups of 16 channels with supervision |
| Filter Times | Configurable: 2 ms / 4 ms / 8 ms / 16 ms |
| Voltage Supervision | One voltage monitoring input per group |
| Optical Isolation | Each channel opto-isolated with LED indicator |
| Mounting | To be used with TU MTUs (e.g., TU818, TU830) |
| Dimensions (W x H x D) | 45 × 119 × 102 mm |
| Weight | 0.15 kg |
| Insulation Voltage | 50 V |
| Dielectric Test Voltage | 500 V AC |
| Protection Class | IP20 (IEC 60529) |
| Equipment Class | Class I (IEC 61140) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What signal type does the DI818 module accept?
A1: It supports 24 VDC input signals, within the range of 18–30 V DC.
Q2: How many input channels are available?
A2: The module provides 32 digital input channels, grouped into 2 isolated groups of 16.
Q3: Are the input groups electrically isolated?
A3: Yes, the 2 groups of 16 channels are individually isolated from each other.
Q4: Does each input channel have an indicator?
A4: Yes, every channel has a status LED showing the ON/OFF state.
Q5: Is digital filtering available on inputs?
A5: Yes, selectable filter times are 2, 4, 8, or 16 milliseconds to suppress noise.
Q6: What happens if the external supply voltage disappears?
A6: The module generates error signals via ModuleBus when supervision detects voltage loss.
Q7: Which MTUs can be used with the DI818?
A7: Compatible with ABB MTUs such as TU818 and TU830 for wiring and bus connectivity.
Q8: Is the module hot-swappable?
A8: No, power must be off before replacing the module to ensure safe operation.
