Technical Specifications
| Feature | DO821 Digital Output Module |
|---|---|
| Number of Channels | 8 |
| Output Type | Relay (NC) |
| Voltage Range | 5 – 250 V a.c./d.c. |
| Maximum Load Current | 3 A |
| Minimum Load Current | 5 mA |
| Max Make Current | 30 A, 200ms, L/R > 10ms |
| Max Break Power | 720 VA a.c. (power factor > 0.4), 40 W d.c. L/R < 40 ms |
| Maximum Cable Length | 600 meters (656 yards) |
| Pick-up Time (max) | 9 ms |
| Release Time (max) | 5 ms |
| Max Operations per Hour | 2000 operations per hour |
| Lifetime Mechanical Ops | >20 x 10^6 |
| Lifetime Electrical Ops | >1 x 10^6 |
| Current Consumption (5V) | 60 mA |
| Current Consumption (24V) | 140 mA |
| Power Dissipation | 2.9 W |
| Output Set (OSP Timer) | 256, 512, 1024 ms |
| Power Supervision | 24/12 V Relay Power Converter Monitoring |
| Isolation | Individually isolated from ground (RIV=250 V) |
| Rated Insulation Voltage | 250 V |
| Dielectric Test Voltage | 2000 V a.c. |
| Dimensions | 45 x 102 x 119 mm |
| Weight | 0.23 kg |
FAQ
Q1: What is the maximum load current for the DO821 module?
A1: The maximum load current is 3A.
Q2: What voltage range does the DO821 module support?
A2: The voltage range is from 5 to 250 volts, supporting both a.c. and d.c.
Q3: What is the minimum load current per channel?
A3: The minimum load current per channel is 5mA.
Q4: How many operations can the DO821 module perform per hour?
A4: The module can perform up to 2000 operations per hour.
Q5: What is the maximum break power for the DO821 module?
A5: The maximum break power is 720 VA for a.c. (with power factor > 0.4) and 40 W for d.c.
Q6: What is the maximum cable length supported by the module?
A6: The maximum cable length is 600 meters (656 yards), applicable for both a.c. and d.c.
Q7: What are the pick-up and release times for the DO821 module?
A7: The pick-up time is a maximum of 9ms, and the release time is a maximum of 5ms.
Q8: What is the weight of the DO821 module?
A8: The weight of the module is 0.23 kg.
