Technical Specifications
| Parameter | Value |
|---|---|
| Article Number | 3BSE028602R1 |
| Type | Digital Output Module |
| Number of Channels | 16 |
| Signal Specification | 24 V DC (19.2 – 32 V DC), 0.5 A per channel |
| Signal Type | Current sourcing, current limiting |
| Redundancy | Supported |
| High Integrity | Yes, SIL3 certified (IEC 61508) |
| Isolation | Groupwise isolated from ground |
| Current Limiting | Short circuit proof |
| Rated Insulation Voltage | 50 V |
| Dielectric Test Voltage | 500 V AC |
| Power Dissipation | 5.6 W (0.5 A x 16 channels) |
| Current Consumption +5 V Modulebus | 45 mA |
| Current Consumption +24 V Modulebus | Max. 50 mA |
| Current Consumption +24 V External | 10 mA |
| Diagnostics | Fault, Run, Warning LEDs, Channel status/error indicators |
| Loop Supervision | Configurable for 50 Ω to 2 kΩ |
| Operating Temperature | 0 to +55 °C |
| Storage Temperature | -40 to +70 °C |
| Relative Humidity | 5–95 %, non-condensing |
| Protection Class | IP20 |
| Approvals | CE, UL, ATEX Zone 2, Marine certifications (ABS, BV, DNV, LR) |
| Compatibility | MTU TU810, TU812, TU814, TU830, TU833, TU842, TU843, TU852 |
| Dimensions | 45 x 102 x 119 mm |
| Weight | 0.20 kg |
FAQ
FAQ
Q1: What is the maximum output current per channel?
A1: The maximum continuous output current per channel is 0.5 A.
Q2: Can the DO880 operate in a redundant configuration?
A2: Yes, the module supports both single and redundant configurations.
Q3: Does the module provide short-circuit protection?
A3: Yes, each output is current limited and short-circuit proof.
Q4: What type of load supervision does the DO880 support?
A4: It supports loop supervision configurable for loop resistance from 50 Ω to 2 kΩ.
Q5: Is the module suitable for safety applications?
A5: Yes, it is SIL3 certified according to IEC 61508.
Q6: What is the protection class of the DO880?
A6: The module is rated IP20 according to IEC 60529.
Q7: Which mechanical units (MTU) are compatible with the DO880?
A7: It is compatible with MTU TU810, TU812, TU814, TU830, TU833, TU842, TU843, and TU852.
Q8: What environmental certifications does the DO880 hold?
A8: The module has CE marking, UL compliance, ATEX Zone 2 certification, and marine approvals from ABS, BV, DNV, and LR.
