Technical Specifications
| Parameter | Description |
|---|---|
| Model | ABB DSAI 303 57120001-CL |
| Input Type | Analog Input |
| Input Signal Range | -10 V to +10 V |
| Input Impedance | 1 MΩ |
| Number of Channels | 4 Channels |
| Input Accuracy | ±0.1% (Full Scale) |
| Sampling Rate | 100 Hz |
| Output Signal | 0-10 V / 4-20 mA |
| Operating Voltage | 24 V DC |
| Operating Temperature | -20°C to +60°C |
| Dimensions | 234 x 27 x 117 mm |
| Weight | 0.105 kg |
| Environmental Humidity | 5% – 95% (Non-condensing) |
FAQ
FAQ
Q1: What is the input signal range of this unit?
A1: The input signal range is from -10 V to +10 V.
Q2: What is the input impedance of this device?
A2: The input impedance is 1 MΩ.
Q3: How many input channels does this unit support?
A3: This unit supports 4 analog input channels.
Q4: What is the input accuracy?
A4: The input accuracy is ±0.1% full scale.
Q5: What is the sampling rate of this device?
A5: The sampling rate is 100 Hz.
Q6: What output signal types are supported?
A6: The supported output signal types are 0-10 V or 4-20 mA.
Q7: What is the operating voltage of the device?
A7: The operating voltage is 24 V DC.
Q8: What is the operating temperature range of the device?
A8: The operating temperature range is from -20°C to +60°C.
