Technical Specifications
| Parameter | Specification |
|---|---|
| Model | DSAI130A |
| Part Number | 3BSE018292R1 |
| Channels | 16 differential analog input channels |
| Input Ranges | ±10V, ±5V, ±2.5V, ±1.25V, ±20mA, ±10mA, ±5mA, 4–20mA (software-configurable) |
| Resolution | 12 bits + sign |
| Common-Mode Voltage (CMV) | Up to 100V |
| Shunt Resistor | 250Ω, 0.1% tolerance |
| Dimensions | 324 × 22.5 × 225 mm |
| Weight | 0.317 kg |
FAQ
FAQ
-
Q1: What is the maximum sampling rate for the DSAI130A analog input board?
A1: The maximum sampling rate per channel is 2.5 kHz when all channels are utilized simultaneously. -
Q2: Can the DSAI130A handle both current and voltage inputs on the same channel?
A2: Yes, each channel is configurable for voltage or current input via software settings. -
Q3: How is channel isolation maintained in the DSAI130A?
A3: The board features differential input design with 100V common-mode voltage tolerance for each channel, ensuring robust isolation. -
Q4: What is the accuracy of the DSAI130A across the full input range?
A4: The typical accuracy is ±0.1% of full scale for voltage inputs and ±0.2% for current inputs. -
Q5: How does the DSAI130A handle signal noise and interference?
A5: The board employs filtering circuitry and differential input configuration to minimize noise and improve signal integrity. -
Q6: Are there specific temperature limits for operation?
A6: The board operates reliably between 0°C and 60°C ambient temperature. -
Q7: Can the DSAI130A be hot-swapped in a running S100 system?
A7: No, the module must be powered down before insertion or removal to prevent damage. -
Q8: How is the DSAI130A calibrated?
A8: Calibration is performed via the associated ABB configuration software, allowing adjustment for offset and gain per channel.
