Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | ABB DSQC 236G YB560103-CD Servo Axis Drive Unit |
| Type | Servo Axis Drive Unit |
| Compatible System | ABB IRB6400 Robot, S4 Control System |
| Voltage Supply | Typically 3-phase 475 V AC |
| Power Consumption | Approx. 6.7 kVA |
| Axis Compatibility | Designed for control of a single robot axis |
| Communication Interface | Backplane VME or proprietary ABB interface |
| Mounting | Rack-mounted inside the control cabinet |
| Cooling Method | Convection or forced air via control cabinet ventilation |
| Safety Features | Integrated with dual Run Chain safety circuit |
| LED Indicators | Diagnostic LEDs for fault, enable, and operation status |
| Dimensions (W × H × D) | 254 × 25 × 245 mm |
| Weight | 1.36 kg |
FAQ
FAQ
Q1: What is the primary function of the ABB DSQC 236G module?
A1: It is used to control the servo motor of a single axis in the ABB IRB6400 industrial robot, integrated into the ABB S4 controller.
Q2: Can this module control multiple axes?
A2: No, each DSQC 236G is dedicated to a single axis. Multiple units are required for multi-axis control.
Q3: What power supply is required for the DSQC 236G?
A3: The module typically operates with a 3-phase 475V AC supply, coordinated through the ABB control cabinet.
Q4: Does it support self-diagnostics?
A4: Yes, it features onboard diagnostic LEDs and is involved in system-level cold/warm boot diagnostics.
Q5: Is the DSQC 236G hot-swappable?
A5: No, power must be disconnected before replacing or inserting this module to prevent damage or injury.
Q6: What should I do if the module fails?
A6: Check the system error logs and LED indicators, then follow ABB’s official troubleshooting or replacement procedures.
Q7: How is the module cooled?
A7: Cooling is typically achieved through natural convection or forced air circulation in the control cabinet.
Q8: Is this module compatible with newer ABB systems?
A8: No, it is specifically designed for the S4 controller and is not compatible with newer systems like the IRC5.
