Technical Specifications
| Parameter | Specification |
|---|---|
| Model | DSQC697 3HAC037084-001 |
| Communication Interface | DeviceNet |
| Supported Protocol | DeviceNet Standard |
| Power Supply Voltage | 24 V DC ± 10% |
| Power Consumption | 2.5 W |
| Operating Temperature | 0℃ ~ 55℃ |
| Storage Temperature | -20℃ ~ 70℃ |
| Relative Humidity | 5% ~ 95% non-condensing |
| Mounting Method | Plug-in Installation |
| Dimensions (mm) | 140 x 10 x 130 mm |
| Weight (kg) | 0.04 kg |
| Indicators | Power status, communication status |
| Compatible Controllers | ABB AC500 Series PLC |
| Communication Speed | 125/250/500 kbps |
FAQ
FAQ
-
Q1: Which devices can be connected to this DeviceNet board?
A1: It supports all sensors, actuators, and devices compliant with the DeviceNet standard. -
Q2: Can the DSQC697 operate in high humidity environments?
A2: Yes, it can operate normally under 5% ~ 95% relative humidity without condensation. -
Q3: Are special tools needed to install DSQC697?
A3: No special tools are required; standard plug-in installation is sufficient. -
Q4: How is the communication speed configured?
A4: The speed can be configured via the controller parameters as 125/250/500 kbps. -
Q5: How to troubleshoot communication failures?
A5: Check DeviceNet wiring, termination resistors, and power status. -
Q6: Is the board hot-swappable?
A6: Hot-swapping is not recommended; power should be turned off before installation. -
Q7: What is the expected lifespan of the board?
A7: Under normal use, the board can last 5+ years. -
Q8: Can it work with non-ABB PLCs?
A8: In theory, it can work with PLCs supporting DeviceNet, but actual compatibility should be tested.
