Technical Specifications
| Parameter | Specification |
|---|---|
| Model | GD C806 B05 |
| Part Number | 3BHE036290R0005 |
| Manufacturer | ABB |
| Product Type | Control Board Module |
| Series | ABB Industrial Drive Control Series |
| Function | Central control and signal processing for drive systems |
| Compatible Systems | ABB ACS and DCS drive families |
| Processor Type | High-performance microcontroller-based design |
| Input Signal Type | Digital and analog inputs supported |
| Output Signal Type | Digital control and communication outputs |
| Communication Interfaces | CAN, PROFIBUS, and proprietary ABB system bus |
| Control Voltage | 24 V DC (nominal) |
| Power Consumption | <10 W |
| Isolation Voltage | 500 V RMS between logic and field circuits |
| Diagnostic Functions | Self-check, watchdog timer, and fault indication |
| Firmware Upgradability | Supported via ABB engineering tools |
| Operating Temperature Range | 0°C to +55°C |
| Storage Temperature Range | -25°C to +70°C |
| Relative Humidity | 5% to 95% non-condensing |
| Cooling Method | Natural convection |
| Mounting Type | Plug-in type to ABB control rack |
| Dimensions | 200 × 150 × 45 mm |
| Weight | 0.45 kg |
FAQ
FAQ
Q1: What is the main purpose of the ABB GD C806 B05 module?
The GD C806 B05 is designed as a control board for managing and coordinating operations within ABB industrial drive systems, ensuring precise process control and communication.
Q2: Which ABB systems are compatible with this module?
It is primarily compatible with ABB ACS and DCS drive systems, serving as a key control interface in those configurations.
Q3: What types of input and output signals does this board handle?
It supports both digital and analog input signals, along with digital outputs for control and communication to external modules or systems.
Q4: Does the GD C806 B05 module include communication interfaces?
Yes, it supports multiple communication interfaces including CAN bus, PROFIBUS, and ABB’s proprietary system bus for seamless data exchange.
Q5: How does the module ensure operational reliability?
It includes self-diagnostic capabilities such as watchdog timers, fault detection, and internal status monitoring to prevent operational failures.
Q6: Can the firmware of this control board be upgraded?
Yes, firmware updates can be performed using ABB’s engineering software tools to maintain performance and compatibility with new system versions.
Q7: What are the typical environmental operating conditions for this module?
The module operates efficiently in environments ranging from 0°C to +55°C with non-condensing humidity levels between 5% and 95%.
Q8: How is the GD C806 B05 module installed within the ABB system?
It uses a plug-in mounting design, allowing easy installation and replacement within the ABB control rack structure without complex rewiring.
