Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | MCS-B 1,3-100-240/24 |
| Part Number | 3AXD50000001438 |
| Product Type | Power Supply |
| Application | ABB ACS880 drive systems |
| Input Voltage | 100–240 VAC, 50/60 Hz |
| Input Voltage Range | 90–265 VAC, 50/60 Hz; 110–300 VDC |
| Output Voltage | 24 VDC |
| Adjustable Output | 22.5–28 VDC |
| Output Current | 1.3 A continuous at 90–170 VAC / 40°C |
| Output Current at Higher Temperature | 1.0 A at 60°C |
| Output Power | Approx. 31.2 W |
| Efficiency | Approx. 82% |
| Inrush Current | <20 A at 230 VAC |
| Hold-up Time | >15 ms at 100 VAC; >100 ms at 230 VAC |
| Protection | Overload / short-circuit / over-temperature protection |
| Safety Class | Class I |
| Approx. Net Weight | 0.16 kg |
| Country of Manufacture | Czech Republic |
| Customs Tariff Code | 85044082 |
FAQ
FAQ
Q1: What is ABB MCS-B 1,3-100-240/24?
A: It is an ABB single-phase power supply providing regulated 24 VDC power for compatible industrial drive equipment.
Q2: What is the ABB part number?
A: The part number is 3AXD50000001438.
Q3: What is the input voltage?
A: The nominal input is 100–240 VAC, 50/60 Hz. The specified input range is 90–265 VAC or 110–300 VDC.
Q4: What is the output voltage?
A: The nominal output is 24 VDC, adjustable from approximately 22.5 to 28 VDC.
Q5: What is the output current?
A: The maximum continuous output is 1.3 A under the specified conditions. At higher ambient temperature, the allowable current is reduced.
Q6: What is the output power?
A: At the nominal 24 VDC and 1.3 A, the nominal output power is approximately 31.2 W.
Q7: What are the dimensions and weight?
A: The exact overall OEM dimensions were not reliably found in the available documentation. The confirmed product weight is 0.16 kg.
Q8: Which ABB drives use this power supply?
A: The part is listed as an accessory/component for ABB ACS880 drive systems.
