Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ABB MCX913-1-5-1 HESG112835/A |
| Type | Multi-Function Relay |
| Dimensions | 270 x 100 x 220 mm |
| Weight | 2.9 kg |
| Supply Voltage | 24–48 V DC |
| Output Type | Relay contact, 250 V AC / 5 A max |
| Input Signal | Digital and analog inputs |
| Response Time | ≤ 20 ms |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Protection Class | IP20 |
| Communication Interface | Modbus RTU, optional Profibus |
| Mounting | Panel or DIN rail |
FAQ
FAQ
-
Q1: What protection functions does this relay provide?
A1: It provides overcurrent, over/under voltage, phase sequence, short-circuit, and overload protection. -
Q2: What is the response time of the relay?
A2: The nominal response time is ≤ 20 ms. -
Q3: Are special tools required for installation?
A3: No special tools are needed; it can be mounted on a panel or DIN rail. -
Q4: Can it be used in high-temperature environments?
A4: Yes, it operates safely between -20°C and +60°C. -
Q5: Which communication protocols are supported?
A5: Modbus RTU is supported, with optional Profibus interface. -
Q6: What is the maximum output load?
A6: The maximum relay contact load is 250 V AC / 5 A. -
Q7: How should input signals be connected?
A7: Digital or analog inputs can be connected according to the wiring diagram. -
Q8: Does the relay have a protection rating?
A8: Yes, it has an IP20 rating, protecting against solid object intrusion.
