Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | IGCT Module |
| Model | 3BHL000764P0001 |
| Dimension | 190 × 140 × 35 mm |
| Weight | 0.35 kg |
| Rated Current | 1200 A |
| Rated Voltage | 4.5 kV |
| Switching Speed | 1.5 kV/µs |
| Maximum Pulse Current | 5 kA |
| Operating Temperature Range | -40°C ~ +85°C |
| Insulation Class | F Class |
| Cooling Method | Air cooling / Forced airflow |
| Connection Type | Bolt terminals |
| Function | High-performance power control and rectifier applications |
FAQ
FAQ
-
Q1: What types of power electronic equipment is this module suitable for?
A1: Suitable for high-voltage inverters, power rectifiers, and high-performance power control systems. -
Q2: What is the recommended switching frequency for the IGCT module?
A2: Typically recommended between 50 Hz and 1 kHz to ensure stable operation. -
Q3: What cooling methods are supported by this module?
A3: Supports air cooling and forced airflow cooling, selectable based on system design. -
Q4: What should be considered during module installation?
A4: Ensure bolt terminals are securely fastened and avoid mechanical and thermal stress to prolong module life. -
Q5: Can the module be connected in parallel to increase current capacity?
A5: Yes, but parallel use requires current sharing design to ensure even distribution. -
Q6: What happens if the operating temperature exceeds the specified range?
A6: Exceeding the temperature range may accelerate insulation aging and degrade device performance. -
Q7: What is the typical lifespan of the module?
A7: When operated within recommended current, voltage, and temperature ranges, it can achieve tens of thousands of switching cycles. -
Q8: How to determine if the module needs replacement?
A8: Replacement is needed if there is abnormal heating, increased conduction voltage, or reduced switching performance.
