Technical Specifications
| Parameter | Specification |
|---|---|
| Model | PM851K01 3BSE018168R1 |
| Type | AC 800M Controller Processor Unit Kit |
| Processor | MPC860, 24 MHz |
| Memory | 12 MB RAM |
| Power Input | 24 V DC (±20%) |
| Voltage Rating | AC 690V, 50/60Hz |
| Current Rating | 16A |
| Battery | Lithium battery (Model: 4943013-6) |
| Communication Ports | 2 × RJ45 Ethernet ports; 2 × RJ45 serial ports (COM3, COM4) |
| Dimensions | 135 × 186 × 119 mm |
| Net Weight | 1.1 kg |
| Protection Level | IP20 |
| Operating Temperature Range | -25°C to +55°C |
| Package Contents | PM851A CPU, TP830 Baseplate, TB850 CEX-bus Terminator, TB807 ModuleBus Terminator, Backup Battery, 4-pin Power Plug (Model: 3BSC840088R4) |
| Country of Origin | Sweden |
FAQ
FAQ
Q1: What is the processor model used in the PM851K01 3BSE018168R1 controller?
A1: The controller utilizes the MPC860 processor, operating at 24 MHz.
Q2: What is the memory capacity of the PM851K01?
A2: The controller is equipped with 12 MB of RAM.
Q3: What are the power input requirements for the PM851K01?
A3: The controller requires a 24 V DC power supply with a ±20% voltage tolerance.
Q4: What communication interfaces does the PM851K01 support?
A4: The controller provides 2 RJ45 Ethernet ports and 2 RJ45 serial ports (COM3 and COM4).
Q5: What is the protection level of the PM851K01?
A5: The controller has an IP20 protection rating, suitable for environments without external enclosures.
Q6: What is the operating temperature range of the PM851K01?
A6: The controller operates within a temperature range of -25°C to +55°C.
Q7: What components are included in the PM851K01 package?
A7: The package includes the PM851A CPU, TP830 baseplate, TB850 CEX-bus terminator, TB807 ModuleBus terminator, backup battery (Model: 4943013-6), and a 4-pin power plug (Model: 3BSC840088R4).
Q8: Where is the PM851K01 manufactured?
A8: The controller is manufactured in either Sweden.
