Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 3BSE082896R1 (PM858K02) |
| Redundancy | Yes |
| Clock Frequency | 33 MHz |
| Performance (1000 boolean operations) | 0.36 ms |
| Memory | 16 MB |
| Available RAM for application | 7.147 MB |
| Flash Memory for Storage | Yes |
| Processor Type | MPC866 |
| Switch Over Time in Redundant Config. | Max 10 ms |
| Applications per Controller | 32 |
| Programs per Application | 64 |
| Diagrams per Application | 128 |
| Tasks per Controller | 32 |
| Cycle Time per Application Program | Down to 1 ms |
| Flash PROM for Firmware Storage | 4 MB |
| Power Supply | 24 V DC (19.2-30 V DC) |
| Power Consumption | 210 mA typ / 360 mA max |
| Power Dissipation | 5.1 W (8.6 W max) |
| Redundant Power Supply Status Input | Yes |
| Backup Battery | Lithium, 3.6 V |
| Clock Synchronization | 1 ms between AC 800M controllers by CNCP protocol |
| Ethernet Channels | 2 |
| Ethernet Interface | 10 Mbit/s, RJ-45 (female, 8-pole) |
| RS-232C Interfaces | 2 (COM3 and COM4) |
| Temperature Operating Range | +5 to +55 °C |
| Temperature Storage Range | -40 to +70 °C |
| Dimensions | 119 x 186 x 135 mm |
| Weight | 2.7 kg (including baseplate) |
FAQ
FAQ
-
What is the maximum number of applications per controller?
-
The maximum number of applications per controller is 32.
-
-
What is the processor type used in the ABB PM858K02?
-
The processor type is MPC866.
-
-
Can the ABB PM858K02 be used in a redundant configuration?
-
Yes, the controller supports redundancy for higher availability.
-
-
What is the power consumption of the ABB PM858K02?
-
The typical power consumption is 210 mA, and the maximum power consumption is 360 mA.
-
-
What is the flash memory capacity for storage?
-
The controller has a 4 MB flash PROM for firmware storage.
-
-
What is the cycle time per application program?
-
The cycle time per application program can go down to 1 ms.
-
-
What are the environmental conditions for the ABB PM858K02?
-
The operating temperature is between +5°C to +55°C, and the storage temperature is between -40°C to +70°C.
-
-
How much does the ABB PM858K02 weigh?
-
The weight of the unit, including the baseplate, is 2.7 kg.
-
