Technical Specifications
| Parameter | Value |
|---|---|
| Article Number | 3BSE076939R1 (PM866AK01) |
| Processor Type | MPC866 |
| Clock Frequency | 133 MHz |
| Performance (1000 Boolean operations) | 0.09 ms |
| Memory | 64 MB total, 51.389 MB available for application |
| Flash PROM for Firmware Storage | 4 MB |
| Power Supply | 24 V DC (19.2–30 V DC) |
| Power Consumption | 210 mA typical / 360 mA max |
| Power Dissipation | 5.1 W typical / 8.6 W max |
| Redundant Power Supply Status Input | Yes |
| Built-in Back-up Battery | Lithium 3.6 V |
| Ethernet Channels | 2 (IEEE 802.3, 10 Mbit/s, RJ-45) |
| RS-232C Ports | 2 (COM3: non-isolated, COM4: opto-isolated) |
| Operating Temperature | +5 to +55 °C |
| Storage Temperature | -40 to +70 °C |
| Relative Humidity | 5–95% non-condensing |
| Vibration Resistance | 0.0375 mm (10–50 Hz), 0.5 g (50–150 Hz), 0.2 g (5–500 Hz) |
| Protection Class | IP20 |
| Certifications | CE, UL, cULus Class 1 Zone 2, DNV-GL, RoHS, WEEE, ISA Secure |
| Dimensions (W × H × D) | 135 × 186 × 119 mm |
| Weight | 1.2 kg |
FAQ
FAQ
Q1: What is the processor type used in the ABB PM866AK01?
A1: It uses an MPC866 processor with a clock frequency of 133 MHz.
Q2: Does the PM866AK01 support CPU redundancy?
A2: This specific model does not support CPU redundancy.
Q3: How much memory is available for applications?
A3: It provides 51.389 MB of RAM available for application use.
Q4: What are the Ethernet capabilities of this controller?
A4: It has two Ethernet channels supporting IEEE 802.3 at 10 Mbit/s with RJ-45 connectors.
Q5: What is the power supply requirement for the PM866AK01?
A5: It operates on 24 V DC within a range of 19.2–30 V DC.
Q6: What is the environmental protection rating?
A6: It has an IP20 protection class, suitable for industrial environments.
Q7: What is the operating temperature range?
A7: The operating range is +5 to +55 °C.
Q8: Which certifications does this product have?
A8: It holds certifications including CE, UL, cULus Class 1 Zone 2, DNV-GL, RoHS, WEEE, and ISA Secure.
