Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | ABB RRFC-5621 64614371 |
| Type | Filter Board |
| Input Voltage | 24 VDC ±10% |
| Function | Signal filtering for analog and digital circuits |
| Channels | 4 channels |
| Frequency Range | 0.1 Hz – 20 kHz |
| Attenuation | Up to 40 dB |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5–95% non-condensing |
| Isolation | 1000 VAC between input and output |
| Certification | CE, UL |
| Dimensions (H × W × D) | 70 × 65 × 20 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: What is the primary function of the ABB RRFC-5621 filter board?
A1: The board provides signal filtering for both analog and digital circuits, reducing noise and improving signal integrity.
Q2: How many channels are available on the board?
A2: The filter board has 4 channels.
Q3: What frequency range does the board support?
A3: The board supports signals from 0.1 Hz to 20 kHz.
Q4: What is the maximum attenuation provided by the filter?
A4: The board provides up to 40 dB of attenuation.
Q5: Can the board operate in high humidity environments?
A5: Yes, it operates safely within 5–95% non-condensing humidity.
Q6: What is the recommended operating temperature range?
A6: The board operates reliably between -20°C and +70°C.
Q7: Does the board provide electrical isolation?
A7: Yes, the board provides 1000 VAC isolation between input and output.
Q8: What maintenance is required to ensure reliable operation?
A8: Periodic inspection for dust accumulation, checking connections, and ensuring no physical damage helps maintain stable performance.
