Technical Specifications
| Parameter | Description |
|---|---|
| Model | SAFT 123 PAC 57411520 |
| Type | Amplifier Pulse Board |
| Input Voltage | 24 V DC |
| Current Consumption | 120 mA |
| Signal Output Type | TTL/CMOS |
| Response Frequency | 0.1 Hz – 10 kHz |
| Impedance | 50 Ω |
| Operating Temperature | -20 ℃ to +70 ℃ |
| Dimensions | 16.5 mm x 50.5 mm |
| Weight | 0.18 kg |
| Connector Type | 2 x 20 pin connector |
| Mounting | DIN rail or modular rack |
FAQ
FAQ
-
Q1: What signal types does this amplifier pulse board support?
A1: It supports TTL and CMOS input/output signals. -
Q2: What is the operating voltage?
A2: The operating voltage is 24 V DC. -
Q3: What is the maximum response frequency?
A3: The maximum response frequency is 10 kHz. -
Q4: What is the suitable operating temperature range for industrial environments?
A4: The suitable temperature range is -20 ℃ to +70 ℃. -
Q5: What are the mounting options?
A5: It can be mounted on a DIN rail or modular rack. -
Q6: What is the signal output impedance?
A6: The output impedance is 50 Ω. -
Q7: What are the dimensions and weight of this module?
A7: Dimensions are 16.5 mm x 50.5 mm, weight is 0.18 kg. -
Q8: Are there any requirements regarding current consumption during use?
A8: The current consumption is 120 mA; the power supply must meet this requirement.
