Technical Specifications
| Parameter | Value |
|---|---|
| Article Number | 3BSE013234R1 |
| Type | Extended |
| Connection | Terminal block |
| Channels | 16 |
| Voltage | 50 V |
| Maximum Current per I/O Channel | 2 A |
| Maximum Current Process Connection | 5 A |
| Dielectric Test Voltage | 500 V a.c. |
| Mounting | DIN rail, both directions |
| Dimensions (W × D × H) | 64 × 120.5 × 110 mm |
| Weight | 0.28 kg |
| Operating Temperature Range | 0 to +55 °C |
| Storage Temperature Range | -40 to +70 °C |
| Relative Humidity | 5 to 95%, non-condensing |
| Pollution Degree | Degree 2 (IEC 60664-1) |
| Protection Class | IP20 (IEC 60529) |
| Certifications | CE, UL, ATEX Zone 2, Marine (ABS, BV, DNV-GL, LR) |
| EMC | EN 61000-6-4, EN 61000-6-2 |
| RoHS / WEEE Compliance | EN 50581:2012 / Directive 2012/19/EU |
| Compatible Modules | AI810, AI815, AI820, AI830, AI843, AO810, AO815, DI810, DO810, etc. |
| Acceptable Wire Sizes | Solid: 0.2–4 mm²; Stranded: 0.2–2.5 mm² (24–12 AWG) |
| Recommended Torque | 0.5–0.6 Nm |
| Stripping Length | 7 mm |
FAQ
FAQ
Q1: What is the maximum voltage supported by the TU830V1?
A1: The maximum rated voltage of the TU830V1 is 50 V.
Q2: How many I/O channels does the TU830V1 support?
A2: The TU830V1 supports up to 16 I/O channels.
Q3: What are the physical dimensions and weight of the TU830V1?
A3: The dimensions are 64 × 120.5 × 110 mm, and the weight is 0.28 kg.
Q4: Can the TU830V1 be mounted in any orientation on a DIN rail?
A4: Yes, it supports DIN rail mounting in both directions.
Q5: Which ABB I/O modules are compatible with the TU830V1?
A5: Compatible modules include AI810, AI815, AI820, AI830, AI843, AO810, AO815, DI810, DO810, and others listed in the documentation.
Q6: What is the operating temperature range of the TU830V1?
A6: The operating temperature range is 0 to +55 °C.
Q7: What environmental certifications does the TU830V1 hold?
A7: It is certified for CE, UL, ATEX Zone 2, and marine approvals (ABS, BV, DNV-GL, LR).
Q8: What is the protection class of the TU830V1?
A8: The protection class is IP20 according to IEC 60529.
