Technical Specifications
| Parameter | Value |
|---|---|
| Article Number | 3BSC840157R1 |
| Module Type | Compact |
| I/O Type | Termination Unit for IS Modules (AI890, AI893, AI895, AO890, etc.) |
| Channels | 8 |
| Mounting | DIN rail, horizontal |
| Terminal Type | 27 gray terminals |
| Voltage | 24 V |
| Max Current per Channel | 2 A |
| Max Voltage | 50 V |
| Dielectric Test Voltage | 500 V AC |
| Wiring Size (Solid) | 0.2 – 4 mm² |
| Wiring Size (Stranded) | 0.2 – 2.5 mm² / 24 – 12 AWG |
| Power Connector Wire Size | 0.25 – 2.5 mm² / 24 – 14 AWG |
| Torque Recommendation | 0.5 – 0.6 Nm |
| Operating Temperature | 0 to +55 °C |
| Storage Temperature | -40 to +70 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Pollution Degree | Degree 2 (IEC 60664-1) |
| Corrosion Protection | ISA-S71.04 G3 |
| Protection Class | IP20 |
| EMC Compliance | EN 61000-6-2, EN 61000-6-4 |
| Safety Compliance | IEC 61131, EN 61010-1/-2-201 |
| Certifications | CE, ABS, BV, DNV-GL, LR |
| RoHS / WEEE Compliance | EN 50581:2012 / Directive 2012/19/EU |
| Equipment Class | Class I (earth protected) |
| Dimensions (W x H x D) | 64 x 194 x 58 mm |
| Weight | 0.17 kg |
FAQ
FAQ
Q1: Which I/O modules are compatible with the TU891?
A1: It supports AI890, AI893, AI895, AO890, AO895, DI890, and DO890 modules.
Q2: What is the maximum voltage and current supported by TU891?
A2: The maximum voltage is 50 V, and the maximum current is 2 A per channel.
Q3: Does the TU891 provide any protection against incorrect module insertion?
A3: Yes, it includes mechanical keying to prevent incorrect module insertion.
Q4: What is the operational temperature range of TU891?
A4: The operating temperature is 0 to +55°C, and storage is -40 to +70°C.
Q5: How is the TU891 mounted?
A5: It is mounted horizontally on a DIN rail with a latch device.
Q6: Is the module compliant with RoHS and WEEE directives?
A6: Yes, it complies with EN 50581:2012 and Directive 2012/19/EU.
Q7: What certifications does the TU891 hold?
A7: It is certified by CE, ABS, BV, DNV-GL, and LR.
Q8: What is the protection rating of the TU891?
A8: The protection rating is IP20 according to IEC 60529.
