Technical Specifications
| Item | Specification |
|---|---|
| Model | UU D148 AE02 |
| Part Number | 3BHE014185R0002 |
| Type | Current Sensor Control Board |
| Series | ABB UU D148 |
| Function | Collects and processes current sensor signals for monitoring and protection in control systems |
| Input Current | 0–20 A / 4–20 mA (depending on application) |
| Output Signal | Analog or digital signal |
| Communication | Backplane bus / fieldbus interface |
| Power Supply | 24 V DC |
| Power Consumption | Approx. 12 W |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -25°C to 70°C |
| Mounting | DIN rail |
| Dimensions | 180 × 60 × 220 mm |
| Weight | 1.0 kg |
FAQ
FAQ
1. What is the main purpose of the current sensor control board?
A1: Collects and processes current sensor signals for monitoring and protection in control systems.
2. What input current types does it support?
A2: Supports 0–20 A or 4–20 mA input, depending on application.
3. What types of output signals are available?
A3: Can output analog or digital signals.
4. What is the power requirement?
A4: 24 V DC power supply.
5. What is the operating temperature range?
A5: The operating temperature is 0°C to 50°C.
6. What are the dimensions and weight?
A6: Dimensions are 180 × 60 × 220 mm, weight approximately 1.0 kg.
7. How is the board installed?
A7: Mounted on a DIN rail.
8. What are the advantages of this control board?
A8: High-precision current signal acquisition, reliable performance, supports monitoring and protection in industrial control systems.
