Allen Bradley 1336-BDB-SP76D PCB Gate Drive Board

FAQ

Q1. What type of product is the Allen‑Bradley 1336‑BDB‑SP76D?
It is a PCB gate drive board used as a drive spare part in Allen‑Bradley 1336STEF adjustable frequency drives.

Q2. What voltages and horsepower does it support?
It is rated for 480 V AC and supports drive control up to 450 HP.

Q3. Which drive frame size is this board designed for?
This board is designed for F‑Frame type 1336 series drives.

Q4. What are the physical size and weight of the 1336‑BDB‑SP76D?
Typical board dimensions are 263 × 58 × 28 mm, and it weighs around 4.5 kg with mounting/hardware.

Q5. Is this part still manufactured by Allen‑Bradley?
This model is considered a legacy/discontinued part and is generally available through surplus or refurbishment sources.

Q6. What drive families is this board compatible with?
It is compatible with various 1336 series drives, especially 1336STEF and similar frames requiring an F‑Frame gate driver.

Q7. Can this board be replaced in the field?
Yes, it can be replaced as a spare part, but proper ESD precautions and power isolation are required.

Q8. Where is this board typically sourced today?
Since it’s legacy/obsolete, it’s typically sourced from surplus inventory, refurbishers, or aftermarket sellers rather than direct manufacturer stock.
