Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley XM Series (Condition Monitoring Module) |
| Model Number | 1440-SDM02-01RA |
| Product Type | Vibration / Condition Monitoring Module (Dynamic Monitoring Module) |
| System Compatibility | Allen-Bradley XM-120 / XM-121 / XM-123 systems |
| Function | Collects and processes vibration, speed, and condition monitoring signals |
| Channels | 2 dynamic measurement channels |
| Input Types | Accelerometer / velocity / displacement sensors |
| Signal Processing | RMS, peak, FFT-based condition analysis (via XM system) |
| Communication Protocol | EtherNet/IP |
| Network Interface | 10/100 Mbps Ethernet |
| Power Supply | 24 V DC |
| Power Consumption | Approx. 7 W |
| Mounting Type | DIN rail or panel-mounted XM base system |
| Configuration Tool | XM Configuration Software / Studio 5000 integration |
| Diagnostic Features | Sensor fault detection, alarm thresholds, event logging |
| Environmental Protection | Industrial cabinet use (non-hazardous location) |
| Operating Temperature | -20°C to 65°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | Approx. 118 × 51 × 87 mm |
| Weight | Approx. 0.25–0.5 kg |
FAQ
FAQ
Q1. What is the 1440-SDM02-01RA used for?
It is used for machine condition monitoring, especially vibration analysis in industrial rotating equipment.
Q2. What system does it belong to?
It is part of the Allen-Bradley XM Series condition monitoring platform.
Q3. What does it measure?
It processes signals from vibration and proximity sensors to detect machine health conditions.
Q4. How does it communicate?
It uses EtherNet/IP for integration with PLCs and control systems.
Q5. How many channels does it support?
It supports 2 dynamic measurement channels.
Q6. Is it a standalone PLC?
No, it is a specialized monitoring module that works within the XM system architecture.
Q7. What is its main application?
It is commonly used for predictive maintenance of motors, pumps, compressors, and turbines.
Q8. What is the weight of the module?
Approximately 0.25–0.5 kg, depending on configuration and housing version.
