Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Industrial AC/DC Switched‑Mode Power Supply |
| Product Family | Allen‑Bradley 1606‑XL Series |
| Part Number | 1606‑XL480E |
| Input Voltage Range | 184 – 264 V AC (continuous) / 270 – 370 V DC (continuous) |
| Short‑Term Input Tolerance | 170 – 280 V AC or 250 – 400 V DC |
| Input Frequency | 47 – 63 Hz |
| Input Current | ~5 A |
| Typical Inrush Current | ~33 A @ ~264 V AC |
| Nominal Output Voltage | 24 V DC |
| Adjustable Output Voltage | 24 – 28 V DC |
| Maximum Output Current | 20 A |
| Output Power | 480 W |
| Efficiency | Up to ~94 % |
| Power Factor | Typical ~0.90 |
| DC‑OK Relay Contact | Yes |
| Protection | Electronic current limiting, auto‑recovery |
| Mounting | DIN‑Rail |
| Degree of Protection | IP20 |
| Operating Temperature Range | –25 °C to +70 °C (with derating) |
| Hold‑up Time | ~31–51 ms |
| Output Ripple & Noise (max) | ~100 mV |
| MTBF | ~469 kh (40 °C) |
| Dimensions (W × H × D) | 65 mm × 124 mm × 127 mm |
| Weight | ~1.2 kg |
FAQ
FAQ
Q1: What type of power supply is the 1606‑XL480E?
It is an industrial AC/DC switched‑mode power supply designed for DIN‑rail mounting.
Q2: What input voltage range does the 1606‑XL480E accept?
It accepts a wide input range, typically continuous 184–264 V AC or 270–370 V DC.
Q3: What is the nominal output voltage of this unit?
The nominal output voltage is 24 V DC, adjustable up to 28 V DC.
Q4: How much output current can it deliver?
The unit can deliver up to 20 A of output current at 24 V DC.
Q5: What are the physical dimensions and weight?
Typical dimensions are 65 mm wide × 124 mm high × 127 mm deep, and weight is approximately 1.2 kg.
Q6: Does this power supply include any protections?
Yes — it features electronic current limiting and auto‑recovery against overloads and short circuits.
Q7: What is the operating temperature range?
It operates from –25 °C up to +70 °C (derating applies at high temperatures).
Q8: Does the 1606‑XL480E provide any diagnostics output?
Yes, it includes a DC‑OK relay contact to signal the power supply status.
