Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Industrial AC/DC Switched‑Mode Power Supply |
| Product Family | Allen‑Bradley 1606‑XLE Essential Series |
| Part Number | 1606‑XLE240E |
| Input Voltage (AC) | 100–120 V / 200–240 V AC, 50/60 Hz (auto‑select) |
| Operational Input Range | 90–132 V AC / 180–264 V AC |
| Input Current | ~2.05 A @ 120 V AC; ~1.23 A @ 230 V AC |
| Nominal Output Voltage | 24 V DC |
| Adjustable Output Voltage | 24–28 V DC |
| Maximum Output Current | 10 A |
| Output Power | 240 W |
| Efficiency (typical) | ~95 % |
| Power Factor (typical) | ~0.97 |
| Hold‑up Time | >46 ms @ rated load |
| DC‑OK Relay Contact | Yes |
| Ripple & Noise (max) | ≤ 50 mV |
| Protection Features | Overload, short‑circuit, thermal protection |
| Connection Type | Screw terminals |
| Mounting | DIN‑rail or wall mount |
| Operating Temperature Range | −25 °C to +70 °C |
| Relative Humidity | 5 % – 95 % (non‑condensing) |
| MTBF | ~661 kh @ 40 °C |
| Dimensions (H × W × D) | 124 mm × 60 mm × 117 mm |
| Weight | ~700 g |
FAQ
FAQ
Q1: What type of product is the 1606‑XLE240E?
It is an industrial AC/DC switched‑mode power supply suitable for DIN‑rail or wall mounting.
Q2: What input voltage range does the 1606‑XLE240E support?
It supports a universal AC input: 100–120 V or 200–240 V, with operational ranges 90–132 V / 180–264 V.
Q3: What is the nominal output voltage and current?
It provides 24 V DC nominal output, adjustable to 28 V DC, with a maximum current of 10 A.
Q4: How much power can the 1606‑XLE240E deliver?
The output power is 240 W.
Q5: What are the physical dimensions and weight?
The unit measures 124 mm × 60 mm × 117 mm and weighs approximately 700 g.
Q6: Does the 1606‑XLE240E have protection features?
Yes, it has overload, short‑circuit, and thermal protections, along with a DC‑OK relay contact.
Q7: What is the operating temperature and humidity range?
The power supply operates from −25 °C to +70 °C and 5 %–95 % relative humidity, non‑condensing.
Q8: What is the efficiency and ripple performance of this unit?
Typical efficiency is ~95 %, and ripple & noise are ≤ 50 mV.
