Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Industrial DC-UPS Module (Uninterruptible Power Supply) |
| Product Family | Allen-Bradley 1606-XLS Performance Series |
| Part Number | 1606-XLS240-UPS |
| Input Voltage | 24 V DC (22.5–30 V DC) |
| Nominal Output Voltage | 22.4–24 V DC (follows input in normal mode) |
| Output Voltage Range | 22.5–30 V DC |
| Rated Output Current | 10 A |
| Power Boost Current | 15 A (short-term) |
| Output Power | 240 W |
| Output Power (Normal Mode) | up to 360 W |
| Battery Type | External 12 V VRLA battery |
| Battery Capacity Range | 3.9–40 Ah |
| Buffer / Backup Mode | Automatic switchover, battery-dependent hold-up time |
| Charging Current | max. ~1.3 A |
| Protection Features | Overload, short-circuit, reverse polarity protection |
| Diagnostics | LED indicators and relay signaling |
| Connection Type | Spring clamp terminals |
| Mounting | DIN-rail (35 mm) |
| Degree of Protection (IP) | IP20 |
| Operating Temperature Range | −25 °C to +60 °C |
| Storage Temperature Range | −40 °C to +85 °C |
| MTBF | ~886,000 h |
| Dimensions (H × W × D) | 124 mm × 49 mm × 117 mm |
| Weight | ~900 g (approx.) |
FAQ
FAQ
Q1: What type of product is the 1606-XLS240-UPS?
It is an industrial DC-UPS module designed to provide backup power for 24 V DC systems.
Q2: What input voltage does the 1606-XLS240-UPS require?
It operates on 24 V DC input with a working range of 22.5–30 V DC.
Q3: What is the output capability of this UPS module?
It delivers 24 V DC with a rated current of 10 A and up to 15 A short-term boost.
Q4: How much power can it provide?
It provides 240 W in buffer mode and up to 360 W in normal operation.
Q5: What type of battery is used?
It requires an external 12 V VRLA battery, typically between 3.9 Ah and 40 Ah.
Q6: How fast is the switchover to battery mode?
The transition is automatic and effectively seamless, ensuring continuous power.
Q7: What are the physical dimensions and weight?
The unit measures 124 mm × 49 mm × 117 mm and weighs approximately 900 g.
Q8: What protections and diagnostics are included?
It includes overload, short-circuit, and reverse polarity protection, along with LED indicators and relay outputs for status monitoring.
