Allen Bradley 1734-IV4 Analog voltage input module

FAQ

Q1. What is the main function of the 1734‑IV4 module?
It accepts and converts up to four analog voltage signals into digital data for processing by the controller.

Q2. How many voltage input channels does it provide?
It provides four independent analog voltage input channels.

Q3. What voltage ranges can it measure?
Typical supported ranges include ±10 V or 0–10 V, configurable within the module’s settings.

Q4. What resolution does the module offer?
The module uses 15‑bit plus sign resolution for analog voltage conversion.

Q5. What power supply is needed?
It is powered by a 24 V DC supply with an acceptable range of about 10–28.8 V DC.

Q6. Does it require a terminal base?
Yes, it mounts on a POINT I/O terminal base (e.g., 1734‑TB / TBS) clipped onto DIN rail.

Q7. What is the operating temperature range?
It is rated for industrial operation from −20 °C to +55 °C.

Q8. What are the physical dimensions and weight?
The module measures approximately 56 × 24 × 75.5 mm and weighs around 0.03–0.06 kg.
