Allen Bradley 1746-IV8 SLC 500 8-Point DC Input Module

FAQ

Q1: What is the Allen-Bradley 1746-IV8?
A: It is an 8-point 24 VDC sourcing input module for Allen-Bradley SLC 500 systems.

Q2: How many inputs does the 1746-IV8 have?
A: It has 8 digital DC inputs, with all 8 points sharing one common.

Q3: What is the operating voltage range?
A: The module operates from 10 to 30 VDC.

Q4: What is the nominal input current?
A: The nominal input current is 8 mA at 24 VDC.

Q5: What is the signal response time?
A: The maximum signal delay is 8 ms for both ON and OFF transitions.

Q6: What is the backplane current consumption?
A: It draws 50 mA from the 5 VDC backplane supply.

Q7: What is the operating temperature range?
A: The specified operating temperature range is 0 to 60°C.

Q8: What are the dimensions and weight?
A: The approximate dimensions are 127 × 38 × 152 mm, and the weight is approximately 0.17 kg.
