Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Allen-Bradley 1746-OB32/D |
| Product Type | Digital DC Output Module |
| Series | SLC 500 |
| Number of Outputs | 32 Outputs |
| Output Type | DC Sourcing |
| Output Voltage | 5–50V DC |
| Output Current per Point | 0.5 A @ 30°C, 0.25 A @ 60°C |
| Maximum Current per Module | 8 A |
| Points per Common | 16 |
| Backplane Current | 190 mA @ 5V DC |
| Isolation Voltage | 1500V AC |
| Signal Delay | ON: 0.1 ms / OFF: 1 ms |
| Leakage Current | 1 mA Maximum |
| Mounting Type | SLC 500 Chassis Mount |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% Non-Condensing |
| Dimensions (H × W × D) | 145 × 35 × 140 mm |
| Weight | 0.30 kg |
| Certifications | UL, CE, CSA |
FAQ
FAQ
Q1: What is the primary function of the 1746-OB32/D module?
The module provides 32 high-density DC sourcing output channels for SLC 500 automation systems.
Q2: What output voltage range does the module support?
It supports DC output voltages from 5V DC to 50V DC.
Q3: How many output channels are included?
The module includes 32 digital DC sourcing outputs.
Q4: What is the maximum output current per channel?
Each output channel supports up to 0.5 A at 30°C and 0.25 A at 60°C.
Q5: Which controllers are compatible with the 1746-OB32/D?
The module is compatible with Allen-Bradley SLC 500 chassis-based controllers.
Q6: Does the module provide electrical isolation?
Yes, it provides 1500V AC isolation between the backplane and field wiring.
Q7: What are the dimensions and weight of the unit?
The dimensions are 145 × 35 × 140 mm, and the weight is approximately 0.30 kg.
Q8: Is the 1746-OB32/D still available?
No, the module has been discontinued by the manufacturer.
