Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-IB32 |
| Manufacturer | Allen-Bradley |
| Product Family | ControlLogix Input Module |
| Module Function | 32-Channel DC Digital Input Module |
| Input Type | DC voltage (sinking) |
| Input Voltage Range | 10–31.2 V DC (nominal 24 V DC) |
| Number of Channels | 32 |
| Input Current | 2.6 mA at 24 V DC (typical) |
| Isolation Voltage | 30V continuous |
| Backplane Current Consumption | 160 mA at 5.1V DC |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non-condensing |
| Vibration Rating | 2 g (10–500 Hz) |
| Shock Rating | 30 g |
| Dimensions | 145 mm × 35 mm × 140 mm (5.7 in × 1.4 in × 5.5 in) |
| Weight | 0.32 kg (0.71 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA |
FAQ
FAQ
Q1. What is the function of the 1756-IB32 module?
It provides 32 DC digital input channels for monitoring field devices in ControlLogix systems.
Q2. What voltage range does it support?
10–31.2 V DC, typically 24 V DC.
Q3. How many input channels are available?
32 independent channels.
Q4. What type of input does this module use?
Sinking DC inputs.
Q5. Can it be installed in any ControlLogix chassis?
Yes, it fits standard ControlLogix chassis slots.
Q6. Is the module hot-swappable?
Yes, it supports insertion or removal under power with proper precautions.
Q7. What types of devices can be connected?
DC sensors, switches, and push buttons.
Q8. Where is this module typically used?
In industrial automation systems requiring high-density DC input monitoring.
