Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-IF8H |
| Manufacturer | Allen-Bradley |
| Product Family | ControlLogix Analog Input Module |
| Module Function | 8-Channel High-Speed Analog Input Module |
| Input Type | Voltage/Current (configurable) |
| Input Ranges | Voltage: ±10V, 0–10V; Current: 0–20 mA, 4–20 mA |
| Number of Channels | 8 |
| Resolution | 16-bit |
| Input Impedance | Voltage: >1 MΩ; Current: 250 Ω |
| Sampling Rate | Up to 200 kHz per channel |
| Isolation Voltage | 30V continuous |
| Backplane Current Consumption | 300 mA at 5.1V DC |
| Accuracy | ±0.1% full scale (typical) |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non-condensing |
| Vibration Rating | 2 g (10–500 Hz) |
| Shock Rating | 30 g |
| Dimensions | 145 mm × 35 mm × 140 mm (5.7 in × 1.4 in × 5.5 in) |
| Weight | 0.36 kg (0.79 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA |
FAQ
FAQ
Q1. What is the function of the 1756-IF8H module?
It provides 8 high-speed analog input channels for voltage and current signals.
Q2. What types of signals can it accept?
Voltage (±10V, 0–10V) and current (0–20 mA, 4–20 mA).
Q3. How many input channels are available?
8 channels, individually configurable.
Q4. What is the sampling rate of the module?
Up to 200 kHz per channel for high-speed measurements.
Q5. What is the resolution of the module?
16-bit resolution for precise analog measurement.
Q6. Can it be installed in any ControlLogix chassis?
Yes, it fits standard ControlLogix chassis slots.
Q7. Is the module hot-swappable?
Yes, it supports insertion or removal under power with proper precautions.
Q8. Where is this module typically used?
In industrial automation systems requiring high-speed analog signal acquisition, such as motion control and process monitoring.
