Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-L81EP |
| Manufacturer | Allen‑Bradley / Rockwell Automation |
| Product Type | ControlLogix 5580 Process Controller |
| Module Function | Programmable Automation Controller (Process/Control) |
| User Memory | 3 MB standard (varies by variant) |
| I/O Memory | 0.98 MB |
| Maximum Digital I/O | 128,000 points |
| Maximum Analog I/O | 4,000 points |
| Non‑volatile Memory | 4 GB Secure Digital (SD) card installed |
| Communication Ports | 1 × Gigabit Ethernet, 1 × USB 2.0 (programming) |
| Ethernet Speed | 10/100/1000 Mbps |
| Tasks Supported | Up to 32 tasks; up to 1000 programs per task |
| Backplane Current Consumption | ~1.20 A @ 5.1 V DC; ~5 mA @ 1.2 V DC |
| Power Dissipation | ~6.2 W |
| Isolation Voltage | 30 V continuous |
| Operating Temperature | –25 to 70°C (–13 to 158°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non‑condensing |
| Vibration Rating | 2 g (10–500 Hz) |
| Shock Rating | 30 g |
| Dimensions | 237.5 mm × 183 mm × 55 mm |
| Weight | ~0.25 kg |
| Installation | ControlLogix 1756 chassis slot |
| Certifications | CE, UL, CSA, ATEX, IECEx, KC, RCM |
| Lifecycle Status | Discontinued (EOL Dec 31, 2026) |
FAQ
FAQ
Q1. What is the purpose of the 1756‑L81EP controller?
It is a high‑performance ControlLogix 5580 series process controller for automation and process control.
Q2. How much program memory does the 1756‑L81EP have?
It includes 3 MB of user memory and dedicated I/O memory for program execution.
Q3. What I/O capacity can this controller support?
It can support up to 128,000 digital I/O points and 4,000 analog I/O points.
Q4. How does it connect to networks?
It has a built‑in Gigabit Ethernet port and a USB port for programming and communication.
Q5. What type of memory card does it use for non‑volatile storage?
A 4 GB Secure Digital (SD) card is installed for non‑volatile program and data storage.
Q6. What environment ranges can the controller operate in?
It operates from –25 to 70 °C, making it suitable for harsh and process environments.
Q7. Is the controller still in production?
No; it is scheduled for end of life on December 31, 2026.
Q8. Where is this controller most commonly used?
In large industrial automation applications requiring high performance, extensive I/O capacity, and robust process control.
