| Product Model | 1756‑M02AE |
| Manufacturer | Allen‑Bradley |
| Product Type | ControlLogix Analog Output Module |
| Module Function | 2‑Channel Analog Output (Voltage/Current) |
| Output Types | Voltage: ±10V, 0–10V; Current: 0–20 mA, 4–20 mA |
| Number of Channels | 2 |
| Resolution | 16‑bit |
| Output Impedance | Voltage: < 1 Ω; Current: 50 Ω |
| Accuracy | ±0.1% full scale (typical) |
| Isolation Voltage | 30V continuous |
| Backplane Current Consumption | 200 mA at 5.1V DC |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non‑condensing |
| Vibration | 2 g (10–500 Hz) |
| Shock | 30 g |
| Dimensions | 145 mm × 35 mm × 140 mm (5.7 in × 1.4 in × 5.5 in) |
| Weight | 0.32 kg (0.71 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA |
FAQ
FAQ
Q1. What is the function of the 1756‑M02AE module?
It provides 2 analog output channels that can be configured for voltage or current signals.
Q2. What output ranges does it support?
It supports voltage outputs (±10V, 0–10V) and current outputs (0–20 mA, 4–20 mA).
Q3. How many channels are available?
Two independent analog output channels.
Q4. What is the resolution of the module?
16‑bit resolution for precise output control.
Q5. Does it require external configuration software?
Yes, it is typically configured using Studio 5000 or RSLogix 5000 software.
Q6. Is the module hot‑swappable?
Yes, it supports insertion or removal under power with proper precautions.
Q7. What is the typical accuracy of the outputs?
Approximately ±0.1% of full scale.
Q8. Where is this module commonly used?
In industrial automation systems for controlling analog devices such as valves, actuators, and variable speed drives.
